1. Intercom globally 3G, support WiFi, Bluetooth
2. Exquisite workmanship,and elegant outlooking
3. Cluster intercom, mass response
4. Embedded high extensibility Android system
5. Chinese and English prompt
6. Shortcut key design, convenient to use
7. Support group call, single call
8. Priority calling, Monitor, Recording
9. Level-to-level administration and dispatch
10. Support GPS Location and track
11. Multi platform support, MYT, RealPTT, WalkieFleet, etc
General Specifications
Network support： WCDMA/GSM
Platform： MTK MT6572
Operate system： Android 4.4.2
Memory： 512MB(ROM)+256MB(RAM)
Speaker+handset： Support
earhpone connector： 3.5mm
GPS： Support
battery capacity： 5200mAh
Dimensions： 160*60*35 (H x W x D mm)
Weight： 243g
Standby Time： 29hours
Electrical Specifications
Working Frequency (Module B18)
WCDMA： Band1 2100MHz; Band8 900MHz;
GSM：GSM850; GSM900; GSM1800; GSM1900
Working Frequency (Module B125)
WCDMA：Band1 2100MHz; Band2 1900MHz; Band5 850MHz
GSM：GSM850; GSM900; GSM1800; GSM1900
Working Voltage DC：3.3~4.2V
Working Current IDLE mode：≤75mA; Data Transmission mode ≤660mA
Working Temperature/Humidity T： -20℃~+55℃; H: 5%~95%
Storage Temperature： -40℃~+90℃
Rated Audio Output Power： 1.3W
Audio Distortion@ Rated Audio： 10%
Charger： 5V 1A Micro USB
Max Output Power： 24dBm~33dBm, ±2dBm
RX sensitivity： ≤-106dBm
