Features
1. Intercom globally 3G, support WiFi, Bluetooth
2. Exquisite workmanship,and elegant outlooking
3. Cluster intercom, mass response
4. Embedded high extensibility Android system
5. Simple and efficient UI, 1.77 inch LCD screen
6. Chinese and English prompt
7. With functional keyboard
8. Shortcut key design, convenient to use
9. Support group call, single call
10. Priority calling, Monitor, Recording
11. Level-to-level administration and dispatch
12. Support GPS Location and track
13. Multi platform support, MYT, RealPTT, WalkieFleet, etc
General Specifications
Network support: WCDMA/GSM
Platform: MTK MT6572
Operate system: Android 4.4.2
Memory: 512MB(ROM)+256MB(RAM)
Speaker+handset: Support
earhpone connector: 3.5mm
GPS: Support
battery capacity: 3800mAh
Dimensions: 174*58*35 (H x W x D mm)
Weight: 221g
Screen size: 1.77 TFT 128(RGB)x160
Standby Time: 23hours
Electrical Specifications
Working Frequency (Module B18)
WCDMA: Band1 2100MHz; Band8 900MHz;
GSM:GSM850; GSM900; GSM1800; GSM1900
Working Frequency (Module B125)
WCDMA:Band1 2100MHz; Band2 1900MHz; Band5 850MHz
GSM:GSM850; GSM900; GSM1800; GSM1900
Working Voltage DC:3.3~4.2V
Working Current IDLE mode:≤75mA; Data Transmission mode ≤660mA
Working Temperature/Humidity T: -20℃~+55℃; H: 5%~95%
Storage Temperature: -40℃~+90℃
Rated Audio Output Power: 1.3W
Audio Distortion@ Rated Audio: 10%
Charger: 5V 1A Micro USB
Max Output Power: 24dBm~33dBm, ±2dBm
RX sensitivity: ≤-106dBm
